Kirjeldus
Main features
- 256 × 192 thermal resolution, high sensitivity detector, NETD less than 35 mK (25°C, F# = 1.0)
- Image processing technology: Adaptive AGC, DDE, 3D DNR
- 1024×768 resolution 0.39 inch OLED display
- Supports distance measurement and hotspot function
- Support video recording and snapshot, built-in EMMC (16GB)
- Up to 4.5 hours of continuous work
Specification
| Thermal Module | |
| Image Sensor | Uncooled Focal Plane Arrays |
| Max. Resolution | 256×192 |
| Frame Rate | 25 Hz |
| Pixel Interval | 12 μm |
| Response Waveband | 8 μm to 14 μm |
| NETD | less than 35 mK (25°C, F# = 1.0) |
| Lens (Focal Length) | 19 mm |
| Detection Range | 900 m |
| IFOV | 0.63 mrad |
| Field of View | 9.24° × 6.94° |
| Min. Focusing Distance | 1 m |
| Aperture | F1.0 |
| Magnification | 1× |
| Image Display | |
| Display | 1024 × 768, 0.39 inch, OLED |
| Palettes | Black hot, white hot, red hot, fusion |
| Exit Pupil | 22 mm |
| Eye Relief | 10 mm |
| System | |
| Record Video | On-board video recording |
| Capture Snapshot | Yes |
| Standby Mode | Yes |
| Uniformity Correction | Auto, Manual, External Correction |
| Storage | Built-in EMMC (16 GB) |
| PIP | Yes |
| DPC | Yes |
| Hotspot | Yes |
| Hot Track | Yes |
| Reticle | No |
| Distance Measurement | Yes |
| Power Supply | |
| Battery | Replaceable
Applicable type: CR123A, RCR123A |
| Battery Operating Time | 4.5 h (25°C, with hotspot off) |
| Anti-reverse Battery connection | Yes |
| Overvoltage Protection | Yes |
| Battery Capacity Display | Yes |
| Type-C Power Supply | 5 VDC, 2 A
Supports external power supply |
| General | |
| Port | Type-C |
| Work Temperature/Humidity | -20°C to 55°C (-4°F to 131°F) |
| Protection Level | IP67 |
| Vibration & Shock | 750 g/1 ms |
| Dimension | 153.2 × 62.5 × 59.2 mm (6.03” × 2.46” × 2.33”) |
| Weight | 419 g without eyepiece and batteries |
