Key Features
● 384 × 288 thermal resolution, high sensitivity detector, NETD less than 35 mK (25 °C, F# = 1.0) ●
Image processing technology: Adaptive AGC, DDE, 3D DNR
● 748 × 561 resolution 0.39 in. OLED display
● Supports distance measurement and hotspot function
● Supports video recording and snapshot, built-in EMMC (16GB)
● Up to 4.5 hours of continuous work
Specification
| Thermal Module | |
| Image Sensor | Uncooled Focal Plane Arrays |
| Pixel Interval | 17 μm |
| Max. Resolution | 384×288 |
| Response Waveband | 8 μm to 14 μm |
| NET | less than 35 mK (25 °C, F# = 1.0) |
| Lens (Focal Length) | 35 mm |
| IFOV | 0.49 mrad |
| Field of View | 10.0° × 8° |
| F Number | F1.0 |
| Frame Rate | 50 Hz |
| Magnification | 1× |
| Image Display | |
| Display | 0.39-inch, OLED, 748 × 561 |
| Pallets | Black hot, white hot, red hot, fusion |
| Exit Pupil | 22 mm |
| Eye Relief | 10 mm |
| Observation Distance | Max. 1235 m |
| Contrast Adjustment | Yes |
| Brightness Adjustment | Yes |
| System | |
| Hotspot | Yes |
| Distance Measurement | Yes |
| Scene Fashion | Jungle, Recognition |
| Standby mode | Yes |
| Video Recording | Yes |
| Picture Snapshot | Yes |
| DPC | Yes |
| PIP | Yes |
| Uniformity Correction | Auto, Manual, External Correction |
| Build-in Memory | 16 GB |
| Build-in Capacity | 550,000 pictures |
| Power Supply | |
| Battery | Replaceable
Applicable type: CR123A, RCR123A |
| Battery Operating Time | 4.5 h (25 °C, with hotspot off)
4 h (25 °C, with hotspot on) |
| Anti-reverse battery connection | Yes |
| Overvoltage Protection | Yes |
| Battery Capacity Display | Yes |
| Type-C Power Supply | 5VDC, 2A
Supports external power supply |
| General | |
| Port | Type-C |
| Working Temperature | -20°C to 55°C (-4°F to 131°F) |
| Protection Level | IPX7 |
| Shock Absorption Design | Yes |
| Vibration & Shock | 750 g/1 ms |
| Dimension (L×W×H) | 153.2 mm × 62.5 mm × 59.2 mm (6.03″ × 2.46″ × 2.33″) |
| Weight | 0.42 kg (0.93 lb) without eyepiece and batteries |
