Termokaamera FALCON FQ35 HIKMICRO

2,733.00€

The HIKMICRO FALCON FQ35 Ir handheld thermal monocular camera is equipped with a 640×512 infrared detector and a 1024×768 OLED display. It supports surveillance, mobile hotspot and other functions. The high-sensitivity built-in thermal detector ensures a clear view even in complete darkness. The monocular is mainly used in scenarios like search and rescue, hiking, travel and hunting, etc.



Tootekood: FQ35 Kategooria:
  • 640×512 resolution with 12μm sensor
  • High sensitivity thermal module NETD < 20 mK (@25°C, F# = 1.0)
  • Replaceable and rechargeable Li-ion battery
  •  Up to 5 hours of continuous operation
  •  Leading thermal imaging technology: Image Pro
  •  1024×768 resolution 0.39 inch OLED display
Thermal Module
Image Sensor VOx Uncooled Focal Plane Arrays
Resolution 640×512
Frame Rate 50 Hz
Pixel Interval 12 μm
Response Waveband 8 μm to 14 μm
NETD Less than 20 mK (@25°C), F# = 1.0
Focal Length 35 mm
Aperture F1.0
Min. Focusing Distance 3.5 m
Digital Zoom 1×, 2×, 4×, 8×
Optical Magnification 1.82
Field of View (H × V), Degrees/m @100 m 12.54° × 10.05°/22.0 m × 17.6 m
Detection Range 1800 m
Image display
Monitor 0.39 inch, OLED, 1024 × 768
Palettes Black Hot, White Hot, Red Hot, Fusion
FFC (Flat Field Correction) Mode Auto, Manual, External Correction
system
Storage Built-in memory module (64 GB)
Record Video Yes
Capture Snapshot Yes
Standby Mode Yes
Hotspot Yes
Hot Track Yes
Power Supply
Power 5 V, 1.95 W
Battery Type Replaceable and Rechargeable Li-ion Battery
Battery Operating Time 5 hours continuous running with CVBS and hotspot function off (@25°C)
General
Work Temperature/Humidity From -30°C to 55°C (-22°F to 131°F); Humidity: 90% or Less
Protection Level IP67
Dimension 190.3 mm ×58.3mm × 65.2 mm (7.49” × 2.29” × 2.57”)
Weight 505 g (1.11 lb)
